Where Are Fire Suppression Systems Most Effective?

Installing suitable fire protection is a commitment to occupant safety and asset preservation. While every building needs some form of defence against fire, deciding where fire suppression systems truly provide their highest level of protection depends on the building’s hazard profile. The best performance is achieved in places where traditional water systems might cause unacceptable collateral damage, or where fire grows exceptionally fast. Understanding these critical environments helps property owners choose the right technology for superior results.

Why Should Data Centres Not Rely on Water Sprinklers?

A fire in a data centre not only threatens the physical structure but also risks catastrophic data loss and prolonged downtime. Using conventional water-based sprinklers can destroy high-value electronics and cause widespread water damage that exceeds the harm done by the fire itself.

In these sensitive areas, gas extinguishers are preferred. These fire suppression systems generally use one of two methods:

• Inert Gas: Naturally occurring gases like nitrogen and argon are discharged to reduce the amount of concentrated oxygen so a fire cannot sustain itself. The remaining oxygen level is then maintained above safe breathing levels
• Clean Agents: Synthetic chemical agents such as Novec 1230 or FM-200 suppress the fire by interrupting the chemical reaction. These agents are electrically non-conductive, leave no residue, and allow for a quick cleanup so operations can resume with minimal delay

The quick detection and clean discharge of these systems mean that a potential disaster is averted without harming what the system is designed to protect.

What Kind of Fire Needs a Wet Chemical Solution?

Commercial kitchens represent a unique and intense fire hazard that water cannot extinguish successfully. Fires can be fuelled by fats, cooking oils, and grease within frying equipment, on cooktops, and throughout extraction canopies. Water applied to burning grease can spread the flaming oil, rapidly increasing the size of the fire.

A specialised wet chemical system is therefore required. These fire suppression systems operate automatically when fusible links detect excessive heat, discharging a unique liquid chemical agent. It works in two main ways to control the blaze:

1. Saponification: The wet chemical reacts with the hot grease or oil to form a soapy foam layer, preventing oxygen from reaching the fuel source and smothering the fire
2. Cooling: The high water content rapidly lowers the temperature of the burning fat, preventing reignition

Activating his system includes automatically shutting down the gas and electrical supplies to the cooking equipment, removing the fuel source entirely.

Why do Manufacturing Plants Need Different Design Approaches?

Industrial sites, including large manufacturing plants, chemical processing facilities, and high-bay warehouses, present the most severe and varied risk profiles. The sheer volume of stored materials and the presence of flammable liquids and gases mean that a standard wet pipe sprinkler system may not provide sufficient protection on its own.

In these environments, fire suppression systems must be designed to deliver massive volumes of extinguishing agent instantly. This leads to the specification of two different types of water-based systems:

• Deluge Systems: Used where the rapid spread of fire is highly likely, such as aircraft hangars or chemical loading areas. Open sprinkler heads connect to a dry pipe network when a separate fire detection system, like smoke or heat detectors, activates. The main valve opens, and water is discharged from all the heads in the protected zone simultaneously. This creates an enormous curtain of water that quickly saturates the area
• Foam Systems: Used for locations storing significant quantities of flammable liquids, like oils or petrol. Foam is mixed with water and discharged through sprinklers or foam generators. The foam blankets the fuel, cooling it and separating the liquid surface from the air.

These fire suppression systems are calibrated precisely to the building’s use and contents, acknowledging that you should halt its development entirely before it compromises critical infrastructure.

Which Structures Gain the Most from Pre-Action Systems?

Pre-action systems are highly specialised fire suppression systems designed to mitigate the risk of accidental water damage. They are most appropriate for spaces containing extremely valuable or sensitive assets where an inadvertent discharge from a single broken pipe or sprinkler head would be disastrous.

Examples of properties that gain maximum value include:

• Museums and archival libraries
• Telecommunications switch rooms
• Refrigerated storage units

A pre-action system requires a two-step activation process to release water into the pipework:

1. The activation of a separate detection system, such as a smoke or heat alarm, must occur first. This confirms a genuine fire threat exists before any water is introduced.
2. The pressure in the piping network will increase only after the detection signal. If a sprinkler head subsequently activates due to heat from a fire, the water is then discharged.

This dual authentication provides a highly protected environment, confirming that water is only used as a last resort, providing superior security compared to a standard sprinkler system.

How Can Compliance Best be Demonstrated Over Time?

The successful deployment of fire suppression systems is not solely about the initial installation. For commercial property owners, demonstrating compliance with British Standards like BS 9251 and Part B of the Building Regulations is paramount for operational licensing and insurance purposes.

This is met through a structured regime of maintenance and testing, serving to protect the initial capital investment and confirming the system’s ongoing function. Activities include:

• Quarterly flow and pressure tests to check the water supply is adequate
• Annual inspections of key components like pumps, control valves, and storage tanks
• Mandatory logging of all maintenance tasks and system modifications

A failure to maintain proper system records and carry out scheduled inspections can void insurance policies and leave the property owner vulnerable to enforcement action. A compliant maintenance schedule is just as important as the original system design.

How to Get Started with a Custom Fire Suppression Design?

Choosing where to deploy fire suppression systems is always guided by the level of risk and what assets are being protected. Fire suppression systems used correctly deliver superior safety, minimising property damage and business interruption.

If you are planning a new commercial build or are considering a retrofit project in a high-risk environment, contact our specialist team today for a consultation tailored to your specific needs.
